Fully automatic steel bar shape and size measuring instrument

Application Scenario

Zimao Optics focuses on providing users with optical overall measurement solutions. In the field of steel bar detection, by softening complex calculations and measurement accuracy to advanced steel bar detection systems, and calculating through software matching after optical+360 rotation scanning, Zimao Optics breaks through the current situation of traditional steel bar measurement and provides users with more accurate and reliable steel bar size measurement solutions.

The principle and advantage of the steel bar optical size detector is to move the detection process forward to the production process, which can be completed offline. At the same time, it uses fully automatic measurement to replace traditional manual measurement, ensuring that data can be reversed in the continuous optimization of the process in the first time.

Production site and laboratory

After quickly clamping the threaded steel bars, RM quickly scans the tested steel bars using a combination of telecentric lens and laser lateral lens, and then obtains the size and length of the transverse and longitudinal ribs of the steel bars through software algorithms

Fully automated system solution

Can be combined with digital weighing and length measuring equipment to provide a complete evaluation report in one click mode

Cooperate with sample sending robots, combined with tensile testing machines, fully automated integrated solution

Experimental data is connected to a central database for seamless integration with digital factories

Advantages and characteristics Steel bar inspection standards Multiple light source selection Multiple light source selection

Fast testing speed, short time, and high efficiency

Covering multiple types of standards and adapting to different testing needs

Breaking through tradition, one-stop inspection of steel bar size

Pre set steel bar testing standards for different countries and regions

Multiple light source selection

Multiple measurement functions

Video Demo
